The EUROCOM MA6018 Auto-Mixing Amplifier from Behringer allows you to distribute audio to speakers in two different zones and page listeners within those zones. This unit also allows for the installation of hybrid multi-zone systems combining distributed music and low-impedance speakers because it is driven by two independent Class-D mono amplifiers. The first amplifier operates with a standard low impedance output while the second features a selectable output voltage of 70 or 100 volts.
| Weight | 14.1 lb (6.4 kg) |
| Audio Input Type | 8x Combo XLR/TRS mic/line, 8x 5-Pin Euroblock mic/line (in parallel), 4x Stereo summed RCA auxiliary, 1x 4-Pin Euroblock page input |
| Audio Output Type | Amplifier Output: 1x 4-Pin female Euroblock, Lo-Z Output: 2x terminals @ 4 Ω, Hi-Z: 2x terminals @ 70/100 V (switchable), Direct Out: 8x 5-Pin Euroblock, Z2/MOH Output: 1x 5-Pin Euroblock |
| Channels | Lo-Z: 1x 4 Ω (minimum), Hi-Z: 1x 70/100 V (switchable) |
| Dimensions | 3.5 x 17.0 x 16.0" (8.8 x 43.2 x 40.6 cm) |
| Dynamic Range | Mic: 65 dB, Line: 80 dB |
| Frequency Response | 50 Hz to 18 kHz (± 2 dB) |
| Input Impedance | Mic: -50 to 0 dBV @ 600 Ω (electronically balanced), Line: -27 to 0 dBV @ 600 Ω (electronically balanced), Auxiliary : -10 dBV @ 10 kΩ (unbalanced) |
| Output Impedance | 0 dBV @ 600 Ω (balanced) |
| Phantom Powered | 24 VDC Switchable on inputs 1 to 8 and Tel/Page input |
| THD | 0.5% @ 1 kHz (rated output) |
